Bolt on Sub-Assembly to Existing Vision System

Bolt on Sub-Assembly to Existing Vision System

This sub-assembly to an existing vision system utilizes a Keyence XG-H500M camera in conjunction with a Keyence CA-DSR15 Back Light (red plate). The “offset tower” located between the lens and the backlight permits things to be mounted, analyzed¬†under the...
Physioject Syringe Press, Semi Auto

Physioject Syringe Press, Semi Auto

This press was created through several of our services, including design development, fabrication, and equipment support of Semi-automated Auto-injector Assembly. Custom tooling and fixtures support the inspection of incoming syringe components. Each assembly station...
1mL Syringe Detrayer

1mL Syringe Detrayer

The 1mL Syringe Detrayer is a manual piece of equipment, used to quickly transfer 1mL Syringes from a 20up Rondo Tray to a custom 20up holder. Start by placing a loaded Rondo Tray onto the Detrayer in the correct orientation. Swipe the handle fully to the right and...
Syringe Label Position Measurement Fixture

Syringe Label Position Measurement Fixture

This fixture utilizes a calibrated gauge ring and caliper to measure Syringe Label Position. The syringe can be affixed consistently utilizing this gauge ring and lite compression spring. With a known surface, our client now has a way to measure label position. This...
